RCF SUB 705-AS II Caisson de basses actif 230 V

The SUB 705-AS II is a compact and powerful bass reflex subwoofer. It is equipped with a 15” high power woofer with 3” voice coil, powered by a 1400 Watt digital amplifier in a robust plywood housing with deep and punchy tuning for a powerful bass. Thanks to the built-in digital stereo crossover (DSP) with adjustable crossover frequency, it can be easily and quickly set up with a satellite speaker. The SUB 705-AS II easily combines with 12” and 15”, ideal for RCF ART and D-Line Series.


Features

• 1400 Watt Digital Amplifier
• 15" Woofer, bass reflex housing
• Stereo crossover
• Switchable crossover frequencies
• Phase-reverse switch
• Electronic equalization, soft limiter and protection
• Stereo XLR input, Stereo XLR signal output

Acoustical Specifications


Frequency Response -3 dB:
40 Hz ÷ 120 Hz

Max SPL:
131 dB

Woofer:
15", 3.0" v.c.


Input/Output Section


Input connectors:
Stereo XLR

Output connectors:
Stereo XLR

Input sensitivity:
-2 dBu / + 4 dBu


Processor Section


Crossover frequencies:
80-110 Hz Hz

Protections:
thermal, rms

Limiter:
soft limiter

Controls:
Volume, EQ, phase, xover


Amplifier Specifications


Total power:
1400 W PEAK

Low frequencies:
1400 W PEAK

Total power:
700 W RMS

Low frequencies:
700 W RMS

Cooling:
convection

Connections:
VDE connector


Cabinet


Cabinet Material:
Baltic birch plywood

Hardware:
Pole mount

Handles:
2 side

Pole Mount/Cap:
yes

Grille:
Steel

Colour:
Black


Physical Specifications


Height:
568/22.36 mm/inch

Width:
430/16.93 mm/inch

Depth:
595/23.43 mm/inch

Net Weight:
28.0/50.70 kg/lbs
