Daslight DVC GZM

Daslight DVC GZM Product Details

The Daslight software is free to download, but requires a Daslight USB or Ethernet interface to convert the data from the software to DMX so the fixtures can process it. Each DVC interface also has stand-alone memory, which allows you to copy your show to the unit and run it without a computer - making it a great choice for a live backup or smaller show.

Contact Connections

Scene control is possible in both live and stand-alone modes using the contact ports on the interface. Bridge the ground pin with pins 1 - 8 of the HE10 connector and start a scene using a push button or relay. The 8 ports can be combined for up to 255 triggers in binary.

Ethernet Connectivity

Connect the GZM to your network and control Daslight over long distances. The network connection also allows the unit to be controlled in stand-alone mode with our simple remote app for iPhone / iPad / Android.

Standalone

Each Daslight interface comes with either flash or microSD memory. This allows you to run programmed shows without a computer in standalone mode. Standalone is perfect for small shows where a computer is not needed or as a backup as well as for building fixed installations. Scenes can be changed using the + and - buttons on the interface, via the contact ports or via network using Easy Remote iPhone/iPad/Android app (DVC4 GZM).

Features:

• 1536 DMX OUT channels (3 universes), expandable to 2048 channels.
• Independent memory on SD card
• Works with Daslight 4 and next generation Daslight 5 software
• USB-B and Ethernet connection
• Supplied with USB-B cable
• Compatible with Windows 10&11 32/64-bit and macOS 10.14 or higher

Technical specifications:

• USB: type B
• XLR: 4 x 3-pin
• Ethernet: RJ45
• Housing: Metal
• Buttons: 3
• Memory: SD card
• Live Channels by default (XLR): 1536
• Live Channels max (XLR): 2048
• Live Art-Net universes: 1
• Live Art-Net universes max: 30
• DMX IN mode: Yes
• Daslight 4: Full
• Daslight 5: Full
• SA Channels by default: 512
• SA Channels max.: 2048
• SD card memory: Yes
• Zones: 5
• Scenes in total: 99
• App/Api trigerring: Yes
• Date & Time: Yes
• Stand alone, buiding with: Daslight 4/5
