Litetruss H43D-C016 2 Way Corner 90°

Litetruss H43D truss system

Do not make any compromises when it comes to event technology, support systems for lighting systems or trade fair and shop construction. Our premium 3-point heavy-duty system H43D has established itself on the market due to its grandiose ratio of space-saving external dimensions. You can also benefit from the great flexibility of the system and from the space it takes up every day for transport and storage. In addition to our standard items, we would also be happy to develop the right special component for your project.

Assembly is quick and easy thanks to the separately available cone connector system. The clean and absolutely non-positive assembly enables a high level of structural stability with only a low material weight. YOU only need a light aluminum hammer for smooth assembly. Like all other Litetruss series, the Litetruss H43D truss system is available in a wide range of lengths and colours.

Technical Specifications:

Edge dimension: 390 mm

Support tube: 48.3x3mm

Filling rods: 20x2 mm

Alloy: EN AW 6082 T6

Weight: 9,4 kg

Size: 81 x 81 x 34.2 cm (LxWxH)

Connectors must be ordered separately
