Defender 3 - Cable Protector 3-channel

Preview: Defender 3 Kabelbrücke 3 Kanäle

€295.08 *

incl. tax, free shipping to Germany
[International shipping costs]

Availability:

Delivery time: 3-5 days

Delivery time: approx. 3-5 days

Item number: 500112885

EAN: 4049521015199

MPN: 85002

Cable Protector 3-channel Heavy-duty,non-slip all-round cable protector made of black,... more

Back to the overview

All information about the product:

"Defender 3 - Cable Protector 3-channel"

Cable Protector 3-channel

Heavy-duty,non-slip all-round cable protector made of black, recyclable polyurethane with built-in carrying handles
Yellow polyurethane lid with high warning effect and secure closure
Patented, self-cleaning lid hinge
3 channels: 1 channel 45 x 50 mm, 2 channels 52 x 49 mm
Load bearing capacity approx. 5 t / 20 x 20 cm
Fire resistance class B2 (DIN 4102), DEKRA-certified (DIN 31000, EN 61537)
Resistant to oil, acid, petrol and short-term contact with solvents
Dimensions 105 x 60.5 x 7.3 cm; Weight 23.7 kg
Reliable protection for cables and personnel for indoor and outdoor use
Curves, end ramps, and connector plugs are available as accessories

3 Big Channels - Most Popular

Featuring a 73 mm profile, 45° curve and end ramps with detachable dovetail connectors the Defender® 3 cable protection system provides versatile cable routing and safe crossing for vehicles and pedestrians. With 3 medium large channels, built-in handles for easy portability and a 5 t per 20 x 20 cm load capacity the 73 mm profile Defender® 3 cable protectors are the perfect all-round choice for a wide variety of applications including heavy wheeled traffic, construction sites, warehouses, carnivals, fairs, trade shows, exhibitions, shopping malls and music events.

Label your cable crossovers! Customise the Defender cable crossovers with your company logo for orders ex 30 pieces for each product. You will find the format requirements in the download pool above the text. Feel free to contact us for more information.

Technical data:

Product type:	Cable Protectors
Type:	3 Channels
Width:	605 mm
Height:	75 mm
Length:	1005 mm
Channels:	3
Width channel 1:	52 mm
Height channel 1:	49 mm
Width channel 2:	45 mm
Height channel 2:	50 mm
Width channel 3:	52 mm
Height channel 3:	49 mm
Material:	Polyurethane
Max load:	Approx. 5 t on a surface area of 20 x 20 cm
Chemical resistance:	Acid-resistant
Chemical resistance:	Oil-resistant
Chemical resistance:	Petrol-resistant
Chemical resistance:	Short-term contact with solvents
Hardness range:	88 Shore ± 4 Shore
Fire protection class:	B2
Temperature range:	-40 to +70 °C
Weight:	23,6 kg
Special feature:	Available also in B1
Special feature:	DEKRA-certified
Special feature:	Inclusive 2 connector plugs
