Smoke Factory Scotty II fog machine

Smoke Factory Scotty II - Compact, handy fog machine

The Smoke Factory Scotty II is a compact, handy fog machine that has been developed for maximum flexibility and user-friendliness. Equipped with a 12 V lead-gel battery and a 400 watt fog output, it enables mains-independent fogging without preheating time. Perfectly suited for mobile applications where instant fog output is required.

Highlights

• Ready to use immediately: Fog without heat-up time thanks to small vaporizer and rechargeable battery.
• Ergonomic design: one-handed operation with direct release on the handle.
• Efficient performance:
  • Continuous fogging for approx. 10 minutes or 150 bursts of 5 seconds each.
  • Fluid consumption: 10 ml/min (max. output).
• Flexible operation:
  • Compatible with analog 0-10 V input for cable or radio remote controls.
  • Expandable with optional accessories such as DMXit! (DMX converter) and Time W.A.R.P. (timer control).
• Quick battery change: battery can be replaced in seconds without tools.
• High safety and quality: Permanent temperature control for optimum vaporization and prevention of residues.
• Quick-release system: Enables the fluid canister to be changed quickly and easily.
• Made in Germany: High-quality workmanship and 3-year guarantee when using original fluid.

Technical data

• Power: 400 watts
• Voltage: 12 V (50-60 A via battery), charger: 100 - 240 V
• Fog time:
  • Continuous fog: Approx. 10 minutes
  • 150 shocks of 5 seconds each
  • Permanent fog at 100%
• Heating time: 1 second
• Fluid consumption: Approx. 10 ml/min (max. output)
• Control options:
  • Analog 0-10 V
  • Stand-Alone
  • Optional: DMX 512 with DMXit!, timer control with Time W.A.R.P.
• Weight and dimensions:
  • Weight: 5.75 kg (incl. battery)
  • Dimensions (L x W x H): 22 x 10 x 21 cm

Included in the scope of delivery

• Smoke Factory Scotty II fog machine
• 12 V lead-gel battery
• Charger
• Operating instructions
