MONACOR DT-140 Hi-fi dome tweeter, 40 W, 4 O

Preview: MONACOR DT-140 HiFi-Dome Tweeter

€20.00 * €30.00 * (33.33% Saved)

incl. tax, plus shipping costs

Availability:

Delivery time: 3-5 days

Delivery time: approx. 3-5 days

Item number: 250132515

EAN: 4007754235050

MPN: 0105670

Hi-fi dome tweeter, 40 W, 4 O 25 mm (1") tweeter with silk dome Consistent radiation... more

Back to the overview

All information about the product:

"MONACOR DT-140 Hi-fi dome tweeter, 40 W, 4 O"

Hi-fi dome tweeter, 40 W, 4 O

25 mm (1") tweeter with silk dome
Consistent radiation pattern due to waveguide in combination with 5" to 6.5" bass-midrange speakers
Neodymium magnet system with heat sink
Very low stray magnetic field

HOBBY HIFI 01/2014

“The product range of MONACOR now includes the DT-140 which is an excellent dome tweeter with perfect measurement values available at an attractive price.”

Technical data:

Impedance (Z):	4 O
Frequency range:	fx-20,000 Hz
Resonant frequency (fs):	1,200 Hz
Rec. crossov. frequ. (fmax.) (12 dB/oct.):	2,500 Hz
Power rating (RMS):	40 W
Peak music power output (MAX):	80 W
Sensitivity:	90 dB/W/m
Voice coil diameter:	Ø 25 mm
Magnet diameter:	Ø 70 mm
Mounting cutout:	Ø 80 mm
Mounting depth:	31 mm
Dimensions:	Ø 103 x 31 mm
Outside diameter:	Ø 103 mm
Width:	Ø 103 mm
Depth:	31 mm
Colour:	black
Admiss. ambient temp.:	0-40 °C
Weight:	0.093 kg
Packing unit:	1
Packing dimensions (W x H x L):	0.11 x 0.04 x 0.11 m
Gross weight:	0.122 kg
Net weight:	0.093 kg
