DAP-Audio MK-822 8 Pair Studio Multicore, Blue Jacket, Price per metre

The DAP mulitpairs are extremely flexible and rugged, suitable for very demanding environments: studio, stage and, most importantly, “on the road". The inner conductors are double colour coded and shielded with alufoil. Each pair is XLPE Isolated and numbered.

• Single shielded multicable
• colour coded
• Tough, roadproof quality
• Each pair OFC-copper shielded

1. Master jacket: flexible roadproof PVC
2. Separator: Twisted cotton paper
3. Pair jacket: Numbered dark-blue PVC Ø 3 mm
4. Pairshield: Silvercoated Alufoil
5. Conductor insulation: Polyethelene red and white Ø 1 mm
6. Inner conductor: Oxygen free copper 99.997 % OFC
7. Earth drain wire: Tinned copper

Each pair with alu-foil (OFC Copper), except MK-3222.
Min. order quantity: 1 m.
Max. on drum: 500 m.Technical data:

Cable Length:	1 m
Maximum Wire Size:	3 mm²
Outer Cable Diameter:	13.5 mm
Outer Isolation Type:	PVC
1st Shield:	Aluminium foil
2nd Shield:	Tinned Copper
Filler Material:	Cotton / Paper
Number of Pairs:	8
