EUROLITE LED TMH-H90 Hybrid Moving-Head Spot/Wash COB wh
€599.00 *
Availability:
Delivery time: 3-5 days
Delivery time: approx. 3-5 days
Item number: 120035095
EAN: 4026397698442
MPN: 51786078
LED Moving Head hybrid spot/wash with color wheel, static and rotating gobo wheel, prism and... more
All information about the product:
"EUROLITE LED TMH-H90 Hybrid Moving-Head Spot/Wash COB wh"
LED Moving Head hybrid spot/wash with color wheel, static and rotating gobo wheel, prism and focus
- Bright spotlight and full-fledged washlight in one device
- 1 powerful LED 90 W COB (chip-on-board) cold white (CW)
- 6 powerful LEDs 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix)
- Positioning within 540° PAN and 200° TILT
- Auto position correction (feedback)
- Exact positioning (16 bit resolution)
- Prism 3-fold rotating; gobo wheel with rotating gobos; gobo wheel with static gobos; Focus motor-driven; color wheel
- Gobo effect
- Color wheel with 7 dichroic filters plus open
Rainbow effect with adjustable speed in both directions - Gobo wheel with static gobos, 7 gobos and open
shake effect - Gobo wheel with rotating gobos, 6 gobos and open
shake effect - Gobos changeable
- Slot-in gobo system for easy gobo replacement
- Integrated show programs
- The device is cooled by cooling fan
- Control via stand-alone; DMX; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
- Flicker-free
- With a beam angle of 13°
- Multicolor LCD display
- Dimmer electronic
- Preprogrammed in Light Captain; EASY SHOW 3
Package contents
- 1 x moving light, 1 x user manual, 1 x power cord, 1 x omega bracket, 1 x safety eyelet
Power supply: | 100-240 V AC, 50/60 Hz |
Power consumption: | 135 W |
IP classification: | IP20 |
Protection class: | Protection class I |
Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
Fuse: | 5 x 20 mm, T 2 A Fuse replaceable |
Lamp type: | LED lamp |
LED: | 1 x 90 W COB (chip-on-board) cold white (CW) 6 x 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix) |
Max. TILT movement: | 200° Exact positioning (16 bit resolution) Auto position correction (feedback) |
Max. PAN movement: | 540° Exact positioning (16 bit resolution) Auto position correction (feedback) |
Flash rate: | 2 - 30 Hz |
Equipment: | Prism 3-fold rotating; gobo wheel with rotating gobos; gobo wheel with static gobos; Focus motor-driven; color wheel |
Color generation: | Color wheel with 7 dichroic filters plus open Rainbow effect with adjustable speed in both directions |
Gobos: | Gobo wheel with static gobos, 7 gobos and open Shake effect Gobo wheel with rotating gobos, 6 gobos and open Outside diameter 21,8mm Image diameter 16mm Shake effect Gobos changeable Slot-in gobo system for easy gobo replacement |
DMX channels: | 25 |
DMX input: | 3-pin XLR (M) mounting version |
DMX output: | 3-pin XLR (F) mounting version |
Cooling: | Cooling fan |
Control: | Stand-alone; DMX; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional) |
Preprogrammed in: | Light Captain; EASY SHOW 3 |
Beam angle: | 13° |
Beam angle (1/2 peak): | Spot 13° Wash effect 20° |
Beam angle (1/10 peak): | Wash effect 38° |
Illuminance in Lux (lx): | Spot cold white (CW) 1m: 49373 lx, 3m: 6186 lx, 6m: 1606 lx Wash effect red (R) 1m: 974 lx, 3m: 101 lx, 6m: 26 lx Wash effect green (G) 1m: 2008 lx, 3m: 244 lx, 6m: 66 lx Wash effect blue (B) 1m: 518 lx, 3m: 49 lx, 6m: 13 lx Wash effect cold white (CW) 1m: 2527 lx, 3m: 257 lx, 6m: 69 lx Wash effect amber (A) 1m: 733 lx, 3m: 83 lx, 6m: 21 lx Wash effect ultra violet (UV) 1m: 16 lx, 3m: 2 lx, 6m: 1 lx Wash effect all 1m: 5885 lx, 3m: 703 lx, 6m: 184 lx |
Housing color: | White |
Display type: | Multicolor LCD display |
Dimensions: | Width: 25,0 cm Depth: 22,0 cm Height: 36,0 cm |
Weight: | 6,50 kg; 6,50 kg |
Noise classification: | Class 3 (clearly perceptible sounds) |
Legal specifications | |
Special product: | Not designed for household room illumination |
Intended use: | Show effect lighting |
