Chauvet DJ SlimPAR T12BT ILS

SlimPAR T12BT ILS

With the SlimPAR T12 BT ILS, you can equip any venue with outstanding wash lighting. This compact device offers flexible control options with Bluetooth®, ILS and DMX programming. It features 12 tri-color (red, green, blue) LEDs. Achieve a great effect quickly and save time laying cables by connecting multiple devices together to create a coherent image.

Highlights

• Compact washlight with integrated wireless Bluetooth® technology
• ILS compatibility for use in the ILS ecosystem
• D-Fi™ USB compatibility for wireless master/slave or DMX control
• Control directly via a smartphone or tablet without additional hardware
• Simple setting of static colors or automatic programs with the optional IRC-6 remote control
• Access to integrated automatic programs via IRC-6 remote control, master/slave or DMX
• Save time when laying cables and extension cables by connecting multiple devices together
• Fits best in the CHS-30 VIP Gear Bag

Specifications

• DMX channels: 3 or 7
• DMX connections: 3-pin XLR
• Light source: 12 LEDs (three-color RGB) 3.3 W, (2 A), 50,000 hours life expectancy
• Strobe rate: 0 to 20 Hz
• Beam angle: 25°
• Field angle: 46°
• Illuminance: 2,071 lux @ 2 m
• Power Linking: 12 units @ 120 V; 20 units @ 230 V
• Input voltage: 100 to 240 VAC, 50/60 Hz (with automatic switchover)
• Weight: 1.1 kg
• Size: 264 x 214 x 76.9 mm
• Approvals: CE, RoHS, FCC
• Power and current: 43 W, 0.6 A at 120 V, 60 Hz
• Power and current: 43 W, 0.4 A at 230 V, 50 Hz
• Bluetooth version: 4.2
• Max Unobstructed Distance: 150 ft (25.7 m)
• Mounting hole of the bracket: 13 mm
• Optional control units: IRC6, ILS Command
• Operating frequency: 2.4 GHz

Included in the scope of delivery

• SlimPAR T12BT ILS
• Connecting cable
• Quick guide
