ISOLED LED CRI927 Linear 48V flex stripe, 8W, IP20, 2700K, 30m roll, 240 LED/m

NEW
€509.88 *
incl. tax, free shipping to Germany
[International shipping costs]
Availability:
Not in stock
Delivery time: approx. 2 weeks
Delivery time: approx. 2 weeks
Item number: 111018135
EAN: 9009377162077
NEW
ISOLED LED CRI927 Linear 48V flex stripe, 8W, IP20, 2700K, 30m roll, 240 LED/m Technical data:... more
All information about the product:
"ISOLED LED CRI927 Linear 48V flex stripe, 8W, IP20, 2700K, 30m roll, 240 LED/m"
ISOLED LED CRI927 Linear 48V flex stripe, 8W, IP20, 2700K, 30m roll, 240 LED/mTechnical data:
Length:20000 mm
Width:10 mm
Height:2 mm
Net weight:278 g
LED type:SMD2110
Nominal voltage:48 V
Nominal power:8 W
Rated power:8 W
Colour temperature:2700K
Beam angle:120°
Luminous flux:660 lm
Light intensity:210 cd
Colour rendering:95 CRI
Lifetime:55000 h
Protection class:IP20
Energy efficiency class:G
Dimmable: Yes
Dimmable via PWM (pulse width modulated DC voltage supply) via upstream controller or dimmable transformer
Material:Copper
Colour:white
Incl. illuminant:No
Special features:Separation point: 50mm with 12 SMD each | Pitch (light point center-center): 4,17mm | 1 unit (roll) = 20m | max. flex stripe length per feed: 20m | length tolerance + thermal expansion: 1% | required cooling mass min. 75 gr/m | incl. 3M 300LSE adhesive tape | Clean and degrease substrate before sticking! Do not peel off again! | Connectors of the group: K1-210 / K2-210 fit | SPECIALITY: Connecting cable on both sides
Further links
We will be happy to advise you!
You can reach us:
Mon-Fri: 08:00 am – 05:00 pm
You can find answers to frequently asked questions here: LTT-InfoCenter
Including buyer protection
Verified identity
Protection of personal data
Learn more about us! Take a look behind the scenes at the LTT Group for an insight into our company.
Downloads for the product:
"ISOLED LED CRI927 Linear 48V flex stripe, 8W, IP20, 2700K, 30m roll, 240 LED/m"
Document type File size
EPREL-Product data sheet
(0.27 MB)
0.27 MB
