ISOLED LED HEQ922/960 Linear CCT flex stripe, 24V DC, 15W kw | 15W ww, 140lm/W, IP20, 5m roll

€172.56 *
incl. tax, free shipping to Germany
[International shipping costs]
Availability:
Not in stock
Delivery time: approx. 2 weeks
Delivery time: approx. 2 weeks
Item number: 111016105
EAN: 9009377153938
ISOLED LED HEQ922/960 Linear CCT flex stripe, 24V DC, 15W kw | 15W ww, 140lm/W, IP20, 5m roll... more
All information about the product:
"ISOLED LED HEQ922/960 Linear CCT flex stripe, 24V DC, 15W kw | 15W ww, 140lm/W, IP20, 5m roll"
ISOLED LED HEQ922/960 Linear CCT flex stripe, 24V DC, 15W kw | 15W ww, 140lm/W, IP20, 5m roll 224Technical data:
Length:5000 mm
Width:10 mm
Height:2 mm
LED type:SMD2835
Nominal voltage:24 V
Nominal power:30 W
Rated power:32 W
Colour temperature:2200K - 6000K
Beam angle:120°
Luminous flux:4200 lm
Light intensity:1337 cd
Colour rendering:90 CRI
Lifetime:53000 h
Protection class:IP20
Energy efficiency class:D
Material:Copper
Incl. illuminant:No
Special features:Separation point: 62,5mm with 14 SMD each | Pitch (light point center-center): 8,92mm | 1 unit (roll) = 5m | max. flex stripe length per feed: 5m | length tolerance + thermal expansion: 1% | required cooling mass min. 140 gr/m | incl. 3M 300LSE adhesive tape | Clean and degrease substrate before sticking! Do not peel off again! | SPECIAL FEATURE: connection cable on both sides
