ISOLED LED CRI9R Linear ST10-flex stripe, 24V, 10W, IP20, green

€102.34 *
incl. tax, free shipping to Germany
[International shipping costs]
Availability:
Not in stock
Delivery time: approx. 2 weeks
Delivery time: approx. 2 weeks
Item number: 111007120
EAN: 9009377069758
LED CRI9R Linear ST10-flex stripe, 24V, 10W, IP20, green Length: 5000mm Width: 10mm... more
All information about the product:
"ISOLED LED CRI9R Linear ST10-flex stripe, 24V, 10W, IP20, green"
LED CRI9R Linear ST10-flex stripe, 24V, 10W, IP20, green
Length:5000mm
Width:10mm
Height:2mm
Net weight:100g
LED type:1400xSMD2110
Nominal voltage:24V DC
Rated power:15 W/m
Colour temperature:GRÜN
Beam angle:120°
Luminous flux:GRÜNlm
Light intensity:2552cd
Lifetime:50000h
Switching cycles:30000
Protection class:IP20
Energy efficiency class:A
Dimmable: Yes
dimmable via voltage drop or pulse-width or pulse frequency modulated DC power supply from a suitable controller/sequencer, dimming actuator or transformer
Material:PCB copper/white
Indoor and Outdoor:Yes
Incl. illuminant:No
Special features:Separation point: 25mm | Pitch (chip center-center): 3.57mm | 1 roll= 5m | Length Tolerance 1% | max. flex band length per feed-in: 5m | Clean and degrease the substrate before gluing! Do not replace again! | Cooling profile required
Further links
We will be happy to advise you!
You can reach us:
Mon-Fri: 08:00 am – 05:00 pm
You can find answers to frequently asked questions here: LTT-InfoCenter
Including buyer protection
Verified identity
Protection of personal data
Learn more about us! Take a look behind the scenes at the LTT Group for an insight into our company.
Downloads for the product:
"ISOLED LED CRI9R Linear ST10-flex stripe, 24V, 10W, IP20, green"
Document type File size
EPREL-Product data sheet
(0.20 MB)
0.20 MB
